Reflux Condenser

Condensers,-Reflux,-Removable-Hose-Connections

Coil style reflux condenser with tightly wrapped coil providing maximum cooling.
Excellent for use with volatile solvents.
Reflux Condenser has a top outer standard taper joint and lower inner drip tip joint.
With Removable Hose Connections.

product description

Reflux Condensers Wholesale Supplier

Product Code	Jacket Length (mm)	Joints Below Joint(mm)	Overall Height(mm)	Hose Connection(mm)
C20051014	100	14/20	205	8
C20051814	180	14/20	305	8
C20051219	125	19/22	205	8
C20051224	125	24/40	275	10
C20051724	175	24/40	325	10
C20052224	225	24/40	375	10
C20052724	275	24/40	425	10

Reflux Condensers With Removable Hose Connections Wholesale Supplier

Product Code	Jacket Length(mm)	Socket/Cone Size(mm)	Overall Height(mm)	Hose Connection(mm)
C20061014	100	14/20	205	8
C20061814	180	14/20	305	8
C20061219	125	19/22	205	8
C20061224	125	24/40	275	10
C20061724	175	24/40	325	10
C20062224	225	24/40	375	10
C20062724	275	24/40	425	10

What is a reflux condenser

A reflux condenser also called a vent condenser or knockback condenser is a vertical tube-side condenser in which the vapor flows upward.

How does a reflux condenser work?

Reflux involves heating the chemical reaction for a specific amount of time, while continually cooling the vapour produced back into liquid form, using a condenser. The vapours produced above the reaction continually undergo condensation, returning to the flask as a condensate.

Types of Reflux Condensers

Basically reflux condensers fall into two categories, namely, Graham Condensers and coil Condensers. In Graham type of condenser vapour flows through the central tube and condenses along its walls to flow back into the reaction flask.
